York 147787 S1-031-09187-000 Single Stage Spark Cntrl Board

BOARD,CNTRL,SPARK,SGL STAGE HT,-40/+176

Board, Control, Spark for Series 1189. Specification

The York 147787 S1-031-09187-000 Single Stage Spark Cntrl Board is manufactured by York Refrigeration.

The York 147787 S1-031-09187-000 is a board with control function. It has an immediate start control device, which is used in power plants to reduce the starting current at generator start up. This is a printed circuit board with single stage spark control instrumentation.

Current board is single stage, solid state, with an unused shunt-circuit interrupter. Includes 147787C91 (Electrode), 147787C92 (Cartridge), 188171H02 (Cover-Terminal), 147786U91 (Spark coil) and 147786U93 (Ignition module 596781A85). This control replaces the following control boards: 147787S1, 147854S1, 103699S1, 103700S1.

This board was developed for use in all 1 stage high temperature industrial systems. It is engineered with industrial grade construction featuring FR4 material, epoxy sealed industrial connectors, offset printing, and ceramic decoupling capacitors for superior electrical characteristics.

The control board serves as a power supply for the spark circuitry and all non-ignition coil circuitry.

The York board is used on all large appliances up to 1987. This board can handle older igniters and still maintain the reliability of the machine. This part is Used to convert electricity into a spark for gas or gas-fired appliances.
